-sold-
Control: Siemens 840 D, Workpiece:  max. clamping diam. 26 mm,
9 main spindles:
- Spindle 1 to 6: max. spindle speed 7,000 rpm
- Spindles 7 to 9: max. spindle speed 10,000 rpm
Swarf conveyor and chiller 21,1 kW, Knoll chiller, With PIETRO CUCCHI PB32 compact bar feeder 26 mm (rounded), 19 mm (squared), 22 mm (hexagonal

-sold-
control siemens 840C, 6-spindle screw machine, six main spindles for bar diameter max. D 51mm, counter spindle for rear machining, threading clutches/drive currently used for counter spindle stopping, 1 CNC compound slide in Position 4, coolant high pressure pump, coolant box with pump and chip conveyor, fire extinguishing unit Kraft & Bauer, Nordmann tool monitoring system, work piece belt
preparation for IEMCA-PRA-bar loader (bar loader not in scope of delivery)
pictures of alike machine
pictured tooling could be different to scope of delivery

-sold-
6 main spindles
pick-off attachment for pos. 6
coolant container with integrated chip conveyor
stock stand and reel; oil mist filter, low running hours, a lot of new parts, revised

video link: https://youtu.be/E0r_gH3nmyA

-sold-

6 main spindles, pick up for rear machining in pos. 6, threading clutches, stock stand and reel , coolant pump, very low running hours, revised in year 2018

video link: https://youtu.be/VQDHFpXuD08

-sold-
8 main spindles, pick up for rear machining (currently not mounted, but in scope of delivery), threading clutches, Independent feed in position 5, 2x sloping recessing unit, 2x longitudinal turning slide, 2x recessing slide 47N, a lot of clamping heads and Rs-feed finger, bar loader IEMCA PRA40/42/P, Chip conveyor: drag type, coolant pump, high pressure coolant pump and filter unit, oil mist filter, Siemens Simatic S5, electronic trip dog control: Balluff, Brass/oil running

-sold-
CNC multispindle automatic lathe, 8 spindle machine, good equipped
http://www.youtube.com/watch?v=_m4X1m_rvrM

-sold-
CNC multispindle automatic lathe in top condition
video:http://youtu.be/B4A9KqoOnt8;

-sold-
cam controlled multispindle screw machine with 8 main spindles
amongst others, the machine is suited for machining 2 parts in 1 cycle (double cross slide in pos. 3 and 7), pick up in pos. 7 (pos. 7 cross slide with double slide for rear machining), control Siemens S7, 2 tool-drive-clutches, coolant-/ chip-box with pump and chip conveyor brand "Ruez", bar loader Iemca PRA40/33P (rack type), tool holders like pictures, documentation in German/Italian.

Videolink: https://youtu.be/oWWHS679AgQ

-sold-
with various tooling revolvers, brand “Knoll” high pressure coolant pump with 3 turbo filters 50µm, hinge chip conveyor brand “Knoll”, active machine cooling system, integrated material bar loader IEMCA SIR for max. 3300mm bars, oil mist filter, fire extinguishing system brand “Kraft & Bauer”

-sold-
stepless Dnt-drive, Hirth coupled spindle drum, thread clutches, scraper chip conveyor, Pietro Cucchi integrated barloader
prepared for (not included): production cycle 2x3 (material feed in pos. 3+6), pick up in pos. 3+6
Videolink: https://youtu.be/JQ39kuHtN1I

-sold-
6 main spindles, pick up for rear machining in position 6, coolant pump, additional coolant pump with magnetic candle filter, [prepared for 2. material feed in position 3, currently option not complete], cleaned and revised, prepared for Iemca barloader



-sold-
6 main spindles, pick up for rear machining, threading clutches (actually used for pick up drive), sorting slip, independent feed in pos. 4, motorized cross slides in position 4 and 5, coolant box with drag chip conveyor, coolant pump, additional coolant pump with magnetic candle filter, work piece belt, the machine is cleaned and revised.
bar loader IEMCA PRA 52/38P (yob. 2001) rack type magazine

video link: https://youtu.be/Ut0oW5PD9x4

-sold-
6 main spindles, pick up for rear machining in position 7 inclusive double slide (XX6), 1x tool drive clutch, various tool holder like pictures, motorized cross slide in position 2 and 5, coolant- and chip box with coolant pumps and magnetic drum filter, magnetic chip conveyor, machine control: Siemens PLC Simatic S7 in combination with Siemens OP7 panel, barloader IEMCA SIR 25F [bundle type], oil mist filter,
(basic prepared material feeding in pos. 3)

-sold-
6-spindle screw machine, cnc compound slide pos. 4, high pressure pump 20 bar, fire extinguishing system Kraft & Bauer, coolant unit, chip conveyor, barloader Iemca PRA 52/42/F.

-sold-
package with 2 pieces CNC controlled multi spindle automatic lathes, used
inclusive a lot of equipment

-sold-

8 main spindles, control Siemens S5 PLC, pick up for rear machining, threading clutches, 2x cross drilling units, frontal milling unit, spindle stop and fixing unit position 2, 3, 4, 5 (double fixing in pos. 2), recessing unit

-sold-

8 main spindles, pick up, threading clutches, frontal milling unit, spindle stop and fixing unit position 5

-sold-
CNC-controlled multi spindle automatic lathe, new
extensive equipment
incl. synchronous spindle
incl. side loader IEMCA
incl. coolant system Knoll
incl. process monitoring ARTIS
Please contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-
6 main spindles, Fanuc control, pick up, threading clutch, Bar loader: IEMCA PRA40/31P from year 2000, chip box with chip conveyor, tooling: like pictures

video link: https://youtu.be/297XIPNjJ28

-sold-

6 main spindles, Fanuc control, pick up, threading clutch, Bar loader: IEMCA PRA40/31P, chip box with chip conveyor, tooling: like pictures

video link: https://youtu.be/D6OHedaHbZs

-sold-
6 main spindles, Fanuc control, pick up, threading clutch, Bar loader: Tornos Robobar MSL 320, chip box with chip conveyor, tooling: like pictures

video link: https://youtu.be/c56yxPAr5X4

-sold-
6 main spindles, Fanuc control, pick up, threading clutch, Bar loader: IEMCA PRA 40/31P; rack type magazine, chip/coolant box with chip conveyor, tooling: like pictures

video link: https://youtu.be/gZDS5Mv810w

-sold-

This machine is equipped with 8 axis and bar loader, chip conveyor, fire-extinguishing unit Kraft & Bauer

Please, contact us for getting more informations and pictures on mail(@)tar-mc.com or www.tar-mc.com

-sold-
with bar loader, chip conveyor, fire-extinguishing unit Kraft & Bauer

-sold-

Cam controlled multi spindle automatic lathe, used
6 main spindles for bars with max. diameter 27mm
pick up/ counter spindle with brake and air cleaning system
Göldenbodt tooling system on cross slides
spindle brakes on main spindles,
additional feeding unit on back side
stock stand and reel for max. bar length: 3.500mm
bar loader IEMCA PRA – rack type
Hinge chip conveyor brand “Knoll” with coolant box (500 liter) and coolant pump with
coolant cartridge filter
tooling: could be different like pictures

-sold-
with barloader IEMCA PRA40/31/P.

-sold-
16 axis Mayfram chip conveyor, fire extinguishing system Kraft & Bauer, Elbaron oil filter, high pressure unit, barloader MSF 522-6

-sold-
with Y-axis, max. bar diametre machine D77mm, HAINBUCH-cuck for BZI65 clamping heads, inclusive barloader Iemca Master 880MP-E, control switched on hours 29500 at 27.03.2018, various equipment like live tools
Visiting under production condition possible

-sold-
CNC units, sawing station, swivel unit, Knoll chip conditioning, Iemca barloader

-sold-
6-fold switching cross for machining tube fix lengths 10mm – 200mm, Cutting to length from the bar, both sides planing, internal and external chamfers, Tubes and solid bars Ø8 – Ø30mm, thin-walled tubes up to 2,5mm wall thickness up to Ø50mm, length measurement and mandrel test with goodpart separation, few operating hours

-sold-
CNC SIEMENS SINUMERIK 840 D, 6 main spindles, max. Diameter 35 mm/38mm, position 6: pick up for rear machining, 2 radial slides: 1x cut off and 1x rear machining, integrated automatic bar loader,
Drum-Clamping HIRTH-coupled, various front machining spindles driven as well as fix
various CNC compound slides, motorized drives for machining spindles in positions 2, 4, 5, 6, Technica High-pressure Coolant cooling unit, Chip Conveyor, fire extinguishing unit “Kraft und Bauer”

-sold-
CNC SIEMENS SINUMERIK 840 D
6 main spindles, max. Diameter 35 mm/38mm, position 6: pick up for rear machining, 2 radial slides: 1x cut off and 1x rear machining, integrated automatic bar loader, Drum-Clamping HIRTH-coupled, various front machining spindles driven as well as fix, various CNC compound slides, motorized drives for machining spindles in positions 2, 3, 4, 6, Technica High-pressure Coolant cooling unit, Chip Conveyor, fire extinguishing unit “Kraft und Bauer”

-sold-
76 times tool-magazine
only chucker-operation

-sold-
8 main spindles, max. bar diameter 35mm, counter spindle for rear machining in Pos. 8, radial slide for back working in Pos. 8, spindle stop (counter spindle), bar stopper in Pos. 1, axial drive for compound slide in Pos. 2, threading motor Siemens, stock stand and reel, bar loader IEMCA PRA IEMCA PRA 52/33P rack type magazine, coolant unit, high pressure coolant pump Knoll AE 1058, coolant chiller Hyfra VWK110-1-5, tooling: like pictures named: „status of tooling by sale - scope of delivery“ (driven end working spindle ISO 30, rotating end working spindle ISO 40, end working spindle fixe ISO30, rotating end working spindle ISO 30, …etc…

Video link: https://youtu.be/K-7tNwOT7Ws

https://youtu.be/ZQpYe-OrnNo

-sold-
8 main spindles, max. bar diameter 35mm, counter spindle for rear machining in Pos. 8, radial slide for back working in Pos. 8, spindle stop (counter spindle), bar stopper in Pos. 1, axial drive for compound slide in Pos. 2, threading motor Siemens, stock stand and reel, bar loader IEMCA PRA IEMCA PRA 52/42P rack type magazine, coolant unit, high pressure coolant pump Knoll AE 1058, coolant chiller Hyfra VWK110-1-5, tooling: like pictures named: „status of tooling by sale - scope of delivery“, (driven end working spindle ISO 30, rotating end working spindle ISO 40, end working spindle fixe ISO30, rotating end working spindle ISO 30, …etc…

video-link: https://youtu.be/tH3_sKtXI-0

https://youtu.be/MCFnTo5oSfE

-sold-
rack type magazine for material bars till diameter 40mm, length 3.300mm



-sold-
**apparently low running hours**
gear driven machine, therefore low problems with electronic, digital position display X- and Y-axis, spindle hole D52mm; spindle nose type C6 DIN 55027, center height: 217,5mm, max turning length 1000mm, spindle max. torque 735,5 Nm, tailstock Morse cone size 5; spindle power max. 5.5kW; max. spindle speed 1600 rev./min (gear speed 2)
hardened bed, vibration-reducing toes, documentation: manual, machine AWF card, CE-declaration from 1998
equipment: chuck brand Röhm; quick change tool holder head size B; steady/lunette unused

video link: https://youtu.be/bQUVaSZWR6g

-sold-

Witzig & Frank rotary transfer machine, used
with 5 horizontal and 10 vertical workstations
separate hydraulic unit
coolant preparation

Please contact us for getting more information and pictures on mail@tar-mc.com or www.tar-mc.com

-sold-

Witzig & Frank rotary transfer machine, used
with 5 horizontal and 10 vertical workstations
chip conveyor
separate hydraulic unit

Please contact us for getting more information and pictures on mail@tar-mc.com or www.tar-mc.com

-sold-

Witzig & Frank rotary transfer machine, used
with 5 horizontal and 10 vertical workstations
separate hydraulic unit
coolant preparation
chip conveyor
connection power approx. 78 kW

Please contact us for getting more information and pictures on mail@tar-mc.com or www.tar-mc.com

-sold-

Witzig & Frank rotary transfer machine, used
with 5 horizontal and 10 vertical workstations
separate hydraulic unit
coolant preparation
chip conveyor
connection power approx. 86 kW

Please contact us for getting more information and pictures on mail@tar-mc.com or www.tar-mc.com

-sold-
6 main spindles with max. outlet bar D 26mm, stepless adjustable spindle speed, electronical trip doc control type Balluff, pick up for rear machining, threading clutches/drive, interface preparation for bar loader type IEMCA PRA [bar loader not in scope of delivery], coolant pump, optional: Oil/chip box with hinge chip belt

cleaned, refreshed and new colored in color scheme grey/blue

tooling: could be different like pictures

video link: https://youtu.be/XJ-3dG9VESo

Please, contact us for getting more informations and pictures on mail(@)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multi spindle automatic lathe
Type: SF26S
Yob: 2000
diameter range: max. 26
number of main spindles: 6
hirth coupled drum;
pick up in pos. 6; independent feed position 4,
threading clutches,
display Siemens Simatic OP27;
control PLC Siemens S7;
interface for IEMCA bar loader Type PRA
(optional I: IEMCA rack type PRA40/33/P; optional II: IEMCA cleaned and painted)
coolant box with hinge chip conveyor
refreshed: The machine is cleaned, partly revised and new colored in color scheme grey/blue

more pictures on request

optional customizing:
CNC upgrade with modern CNC compound slide(s) on cross positions

The machine could be visited under power.

The scope of delivery regarding the tooling equipment could be different like pictures.

video link: https://youtu.be/GMOznJTrgYw

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: AF32S Dnt
Yob: 1997
diameter range: max. 32mm
number of main spindles: 8
counter spindle / pick up for rear machining in position 8
motorized adjusted cross slides in pos. 4, 5, 6
independent feed in pos. 5
threading clutches
spindle stop unit (for example for cross drilling) currently not active
display Siemens WS400-20
coolant box with chip conveyor
barloader IEMCA PRA40/42/, yob 1997, bundle type
fire extinguishing unit -Kraft & Bauer-
The scope of delivery of tooling will be different like pictures.

Please, contact us for getting more informations and pictures on mail(@)tar-mc.com or www.tar-mc.com

-sold-
Manufacturer: INDEX
Machine type: CNC vertical turning machine
Type: V160 (G)
Yob: 2011
main spindle:
D65mm, C-axis
CNC compound slide X1.Z1
tool revolver 1 with 12 stations (driven) and Y1-axis and B1-axis

counter spindle:
D65mm, axis X3, C-axis
tool holder 3 with YZB-axis
tool revolver 3 with 12 stations (driven) with Y-B-axis

INDEX-control C200-4D with electronic shaft
frequency 60Hz; TN-net

Please, contact us for getting more informations and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled spindle automatic lathe
Type: SF32Dnt
Yob: 1991
diameter range: max. 32mm
number of main spindles: 6
control Siemens S5 PLC, electronic trip dog control Type “Balluff”,
stepless adjustable spindle Drive “Dnt”, pick up for rear machining
threading clutches, stock stand and reel,
interface for bar loader IEMCA PRA enclosed,
bar loader IEMCA PRA 40/42/F (bundle type),
tooling: could be different like pictures

The machine is cleaned, revised and new colored in scheme: grey / blue
tooling: could be different like pictures

videolink: https://youtu.be/2tdQMErB_eE

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: INDEX
Machine type: Double spindle automatic lathe
Type: G200
Yob: 1998
number of main spindles: 2
control Index C200-4 (Siemens 840C)
Hinged belt conveyor Knoll 400S-1/200
loading handling Index WHU 100 (in need of overhaul)
The machine could be visited under power approx. until March 2020.
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: multi spindle automatic lathe
Manufacturer: GWM
Type: G20-6AC
Yob: 2013
Including IEMCA bar loader
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: Tool Universal Grinding Machine manual
Type: WU50
Yob: 1996
with 500mm grinding length
standard version with space diagonal grinding head
Operating elements on the front and rear of the machine
Articulated piece with vice and grinding wheel arbor
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: 2D laser cutting machine
Manufacturer: Trumpf
Type: Trulaser 1030
Yob: 2012
Power: 2500 watts
Laser beam on: 3990:00
workpiece max. weight 575kg
Max. material thickness: structural Steel 15mm; stainless steel 6mm; aluminium 5mm
Sheet support accessible on both sides
Easy to operate and clearly arranged control panel
High-quality TFT-color display with touch screen function
Programming directly from *.dxf
Teleservice via Internet
USB interface / RJ-45 network connection
Operating instructions / documentation / machine parameters
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF26S
Yob: 1999
diameter range: max. 26
number of main spindles: 6
hirth coupled drum, pick up in pos. 6; independent feed position 4, threading clutches, display Siemens Simatic OP27, control Siemens S7, Brankamp tool monitoring, IEMCA bar loader rack type PRA40/33/P, coolant box with hinge chip conveyor
The machine is cleaned, revised and new colored in scheme: grey / blue

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF32S-Dnt
Yob: 1992
diameter range: max. 32
number of main spindles: 6
stepless adjustable Dnt-drive, Hirth coupled drum
pick up in pos. 6
independent feed in pos. 1, 2 ,4 ,5
stock stand and reel,
coolant box with hinge chip conveyor and coolant pump
cleaned, partly revised and new colored in color scheme grey/blue
tooling: could be different like pictures

video link: https://youtu.be/eH-KbmmfGA4

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: Turret punch press
Manufacturer: Finn-Power
Type: X5-25
Yob: 2006
NC control Fanuc 0iP, 256 kB working memory
working area 1.250mm x 2.500mm without repositioning
punching force: 230 kN
Basic stroke function
2 clamping claws with central locking
14x stationary tool holders (2x A, 9x B, 2x C, 1x D)
1 piece tool stations Multitool MT 10-16
2 pieces of rotatable tool holders (1x Bi, 1x Di)
Brush tables
Additional tables for max. sheet size (1.250mm x 2.500mm)
Air-cooled Oil cooler
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

brand: IEMCA PRA 40/42 F
type: bundle
bar length, max.: 4.200mm
bar diametre, max: D40mm
optical refreshed:
The machine is cleaned, partly revised and new colored in color scheme grey/blue
more pictures on request
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF67
Yob: 1990
diameter range: max. 67mm
number of main spindles: 6
prepared for pick up for rear machining in pos. 6 (pick up optional)
threading clutches, stock stand and reel
coolant pump
[optional: cleaning and revising]
video link: https://youtu.be/Cp03hJLAoaI
more pictures on request
optional customizing:
CNC upgrade with modern CNC compound slide(s) on cross positions
The machine could be visited under power.
The scope of delivery regarding the tooling equipment could be different like pictures.
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com



-sold-

article: Automatic punching press
Make: ebu Burkhardt
Type: STA200/2000 P2R
year of construction: 2009
Punching press: ebu Burkhardt STA200/2000 P2R, nominal force 2000 kN (~ 200t)
ram surface: W 2000 x D 1000 mm, table surface: W 2000 x D 340 mm, multi-part table; Max. installation height 600mm with largest stroke in TDC
Stroke rate range 20-200 1/min; maximum installation height 600mm; ram adjustment max. 120mm; ram stroke 16 - 160mm
Further details: Hydraulic overload protection, hydraulic connecting rod clamping, hydraulic ram height adjustment, fully automatic stroke adjustment, ram weight compensation, TDC correction electronic, planetary gear, control I, press force measuring device, pendant control panel, movable shielding front, rear, side; Mould clamping system hydraulic, reverser (return), electric stroke counter, suspension bridge, "mould safety" function,
Temperature monitoring: main bearing, support bearing, conrod bearing, oil cooler, roller block strips for simplified tool change, operating modes: two-hand set-up (jog), set-up creep speed, automatic continuous run; main motor 37kW infinitely variable drive (frequency-controlled three-phase drive) with temperature monitoring, and much more...
also included in the scope of delivery:
Feeding device: ebu Burkhardt EVS 320, passage width 320mm, passage thickness 4mm, max. feed speed 150m/min
Straightener: ebu Burkhardt RE9.60-320, passage width 320mm, passage thickness 4mm, passage speed 25m/min
Strap insertion aid: ebu Burkhardt EFH 60-320
Loop bridge: ebu Burkhardt SBR 60-320
Infeed aid: ebu EFH 60-320
Coiler: ebu Burkhardt HS 25-320, strip width 320mm, max. coil outer-Ø 1400mm, coil inner-Ø min. 380mm - max. 530mm
Safety fence
(excluding conveyor belts at the end of the line)
We can send you more pictures on request.
The machine can be inspected under power.
The tooling of the scope of delivery may differ from the pictures.
Video link: https://youtu.be/cJ77RNulEQM
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: Vertical machining centre
Manufacturer: DMG Deckel Maho
Type: DMC 64 V linear
Yob: 2003
Coolant pumps new
At 41339 operating hours the spindle was changed, so now the new spindle has a running time of approx. 14.000 hours.
Machine can be inspected under power
Price: 16.000,00 EURO, net; Pricing in EURO.
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

High-precision CNC lathe with linear cross slide, second-hand
with main and counter spindle
Machine has only been used for reworking, so has only done light machining work!
Control: Siemens Sinumerik 840Dsl
Main spindle: maintenance-free motor spindle
Bar capacity. D26mm
Max. speed: 6000 rpm
Tool star turret, with individual drive of all tool stations (max. 6000 rpm)
Counter spindle: maintenance-free motor spindle
Bar passage. D26mm
Max. speed: 6000rpm
2 pcs. speed increase of motor spindle D26mm to 8.000rpm
Conveyor belt Blank feeding
Loading system type IB (integrated loading)
Unloading system of the counter spindle
Additional gripping system for positional depositing of the workpieces on the workpiece conveyor / part detection
Unloading conveyor axially in the machining area
Chip processing container with coolant pump
Adjustment microscope for main and counter spindle
Nordmann tool monitoring
Profibus master interface
Network interface
A total of 4 similar machines are available - package sale possible
Video-Link: https://youtu.be/yE_-piQ6VF4
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF67
Yob: 1991
diameter range: max. 67mm
number of main spindles: 6
This is a sample image
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF81
Yob: 1991
diameter range: max. 81mm
number of main spindles: 6
This is a sample image
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF100L
Yob: 1991
diameter range: max. 100mm
number of main spindles: 6
This is a sample image
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: multi spindle automatic lathe
Manufacturer: Schütte
Type: SF32S
Yob: 1992
six main spindles,
hirth coupled drum;
pick up in pos. 6, for rear machining
interface for IEMCA bar loader Type PRA (optional I: IEMCA PRA40/42/F)
coolant box with chip conveyor
Schimpke coolant chiller DK48-V/S0
oil mist filter Elbaron
oil running
The configuration of tooling  will be different like pictures.
more pictures on request
The machine could be visited under power.
The scope of delivery regarding the tooling equipment could be different like pictures.

video link:  https://youtu.be/wvT2cS1a93o

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Machine package consisting of:
1x Traub TBH80
1x Traub TK60
1x spare parts package
The machines were used exclusively in plastics processing!
photo link: https://drive.google.com/drive/folders/1--0SHUyM-U6GM_tDV6qtM9Y6y9PuDB_o?usp=sharing
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: CNC multi-spindle automatic lathe
Manufacturer: Schütte
Type: SC7-46
Yob: 2013
six main spindles,
for bars up to D=46mm
CNC multi-spindle automatic lathe for bars up to D=46mm
Axial Y-axis in position 2,3,4 and 5
Radial Y-axis in position 1,2,4 and 6
incl. Cucchi integral loader
incl. Knoll coolant treatment
incl. Hydac cooling
The scope of delivery regarding the tooling equipment could be different like pictures.
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

article: Automatic punching press
Make: ebu Burkhardt
Type: STA-S320/2000 P2R
year of construction: 2005
Punching press: ebu Burkhardt STA-S320/2000 P2R, nominal force 3200 kN (~ 320t)
Plunger surface: W 2000 x D 1300 mm, table surface: W 2000 x D 1300 mm
max. installation height 700mm with largest stroke in TDC and slide adjustment at top; slide adjustment travel max. 120mm; slide stroke 20 - 200mm
further details of the machine: see detail attachment
further included in delivery:
including feed, scrap belt, aluminium head plate
excluding the belt system, as well as the conveyor belts at the end of the line.
The machine can be inspected under power.
The tooling of the scope of delivery may differ from the pictures.
Video link: https://youtu.be/zrIwWS-ka_A
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Benzinger GOFuture B1 (internal Benzinger 1.2), yob 2015, our ID #61801
High-precision CNC lathe with linear cross slide, second-hand.
Machine was only used for finishing, so only did light machining work!
Control: Siemens Sinumerik 840Dsl
Main spindle: maintenance-free motor spindle
Bar capacity: D26mm
Chip processing tank with coolant pump: 30l/min at 5bar
Loading and unloading device type IB
Additional gripping system for positional depositing of workpieces on unloading belt
Linear tool system B1 me tool block with 3 bores
Spindle attachment for collet chucks 363E (clamping D 1 to 22mm, max. passage 18mm)
C-axis main spindle incl. transaxis function
Adjusting microscope B1 and B2 16x magnification
Coolant supply through clamping cylinder of the spindle
Speed increase of motor spindle D26mm to 8.000rpm
Nordmann tool monitoring
Profibus-Master interface
Milling/drilling unit
Hinged belt conveyor Knoll
Compact coolant unit Knoll with centrifugal pumps
MBE interface
Small fire extinguishing system Kraft and Bauer
Network interface for CB-remote
A total of 4 similar machines are available - package sale possible
Video-Link: https://youtu.be/mWICc9SdeL0
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

High-precision CNC lathe with linear cross slide, second-hand.
Machine was only used for finishing, so only did light machining work!
Control: Siemens Sinumerik 840Dsl
Main spindle: maintenance-free motor spindle
Bar capacity. D26mm
Chip processing tank with coolant pump: 30l/min at 5bar
Loading and unloading device type IB
Additional gripping system for positional depositing of workpieces on unloading belt
Linear tool system B1 me tool block with 5 bores
Adjusting microscope 16-fold magnification
Coolant supply through clamping cylinder of spindle
Speed increase of the motor spindle D26mm to 8.000rpm
Nordmann tool monitoring
Profibus-Master interface
Milling/drilling unit
Hinged belt conveyor Knoll
Compact coolant unit Knoll with centrifugal pumps
Network interface for teleservice
A total of 4 similar machines are available - package sale possible
Video-Link: https://youtu.be/3m59cYqnEAI
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

High-precision CNC lathe with linear cross slide, second-hand.
Machine was only used for finishing, so only did light machining work!
Control: Siemens Sinumerik 840Dsl
Main spindle: maintenance-free motor spindle
Bar capacity. D26mm
Chip processing tank with coolant pump: 30l/min at 5bar
Loading and unloading device type IB
Linear tool system B1 me tool block with 3 bores
C-axis main spindle incl. transaxis function
Adjusting microscope B1 and B2 16x magnification
Coolant supply through clamping cylinder of the spindle
Speed increase of motor spindle D26mm to 8.000rpm
Nordmann tool monitoring
Profibus-Master interface
Milling/drilling unit
Hinged belt conveyor Knoll
Compact coolant unit Knoll with centrifugal pumps
MBE interface
Small fire extinguishing system Kraft and Bauer
Network interface for CB-remote
A total of 4 similar machines are available - package sale possible
Video-Link: https://youtu.be/r7slQfb1exM
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Universal lathe, second-hand
control: Siemens Sinumerik 810D
turning length: 1000mm
Turning D over bed: 640mm
Turning-D over cross slide: 435mm
centre height: 315mm
Spindle head according to DIN 55027: Size 8
Spindle bore: D62mm
Chip conveyor with coolant device
Function, as with conventional machine, additionally with constant cutting speed
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: SF81
Yob: 1987
six main spindles,
for bars up to D=81mm
gripper (currently not mounted, enclosed)
bar guide for approx. 4,000 mm bars
electronic trip dog control Balluff
threading clutches
coolant pump, Additional coolant pump
various accessories, such as cams, change gears, tool holders, clamping and feed collets, etc.
video link: https://youtu.be/jSLRdrodmlg
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: cam-controlled automatic lathe (2 pieces in a package)
Manufacturer: ERGOMAT
Type: TD26
year of construction: 2005 & 2006
loading magazine: IEMCA BOSS 332 E
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: Lathe
Manufacturer: GDW
Type: LZ280VS
Yob: 2010
pressure collet system with max. nominal passage D=42mm
extensive accessories, such as 3-jaw chuck etc.
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: 3-axis HSC machine
Manufacturer: Röders
Type: RXU 1401
year of construction: 2020
Spindle hours: 1.485h
Machine on: 3.093h
Programme on:1.456h
Equipment:
- Spindle type: MFW1709/30 VC HSK A63
- Rotary feed-through Milling spindle
- Milling spindle 100-30.000 1/min, 20 KW (S1)
- Compressed air through milling spindle
- Spindle compensation
- Tool changer 90-fold
- Minimum quantity lubrication Lubrix V5-1
- Lubrix with various parameters adjustable via control system
- Lifting Z-axis
- 3D measuring probe
- Oil mist extraction
- Chip conveyor
- Machine without drilling emulsion
- Working area 1.400x1.050x600mm
- Clearance height machine table spindle nose
- Workpiece weight 3.000 Kg
- Linear motors
- Feed rate 0-60.000 mm/min in all axes
Accessories:
- Magnetic table Fa. Schunk 1.000x1.000mm with control system

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: AG20
year of construction: 1999
Eight spindle automatic lathe
8 main spindles
max. nominal passage D=20mm
gripper for backworking in position 7
CNC compound slide position 5 and position 6
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
subject to sale and mistakes

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: AG20
year of construction: 1999
Eight spindle automatic lathe
8 main spindles
max. nominal passage D=20mm
gripper for backworking in position 7
motorised cross slide adjustment position 4
CNC compound slide position 5 and position 6
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
subject to sale and mistakes

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: AG20
year of construction: 1998
Eight spindle automatic lathe
8 main spindles
max. nominal passage D=20mm
gripper for backworking in position 7
motorised cross slide adjustment position 4
CNC compound slide position 5 and position 6
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
subject to sale and mistakes

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Schutte
Type: AG20
year of construction: 2000
Eight spindle automatic lathe
8 main spindles
max. nominal passage D=20mm
Control: Siemens 840D
CNC cross slides in positions 2 and 5;
mechanically driven cross slides in the positions: 1, 3, 4, 6, 7, 8;
mechanically driven longitudinal slides in the layers: 1, 2, 3, 4, 6, 8;
pick up in the position: 7
spindle detection;
hydrostatic drum bearing;
Spindle stop device in one position (pneumatically selectable / deselectable)
electrical drive module Siemens, for connecting a cross drilling device
1 piece tool drive coupling (currently for gripper);
bar guide 3300mm
Loading magazine as rear loader: IEMCA PRA40/33F, type bundle loader;
Pneumatic collecting device for ejection of initial & residual pieces
KM bin with Ruez channelling belt conveyor and magnetic roller filter
KM recooling Schimpke

Video link (old video, not quite up to date): http://youtu.be/YLom9wDMUts

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Manufacturer: Schütte
Machine type: cam controlled multispindle automatic lathe
Type: SF20
Yob: 1990
diameter range: max. 20
number of main spindles: 6
control: Siemens S5 PLC, electronical trip dog control type „Balluff“, gear box for thread milling (2 pieces), pick up for rear machining in pos. 6, work piece sorting shute, coolant pump, threading clutches, stock stand and reel, tooling: could be different like pictures
partly revised inclusive new spindle bearings of the main spindles
interface for IEMCA bar loader
option: barloader: IEMCA-PRA 40/33 P -rack type-

Video-Link: https://youtu.be/7MueLSQH3AM

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Universal Vertical Milling Machine, second-hand -great condition, low spindle hours-.

Model: CMX 600 V
Control: DMG MORI SLIMline Multi-Touch Control - Operate on SIEMENS
travel: X/Y/Z - 600/560/560mm
Table: 900 x 560mm
Speed: 20 to 12.000 rpm
Tool holder SK40
Tool magazine for 30 tools with double gripper
Production package 1
External handwheel
Preparation for rotary table (4th axis) Peiseler ATC 125
Renisaw probe kit for Siemens
Chip tray with chip conveyor and coolant pump
Sold without tools and machine vice
The machine could be visited under power.
The scope of delivery regarding the tooling equipment could be different like pictures.

video link: https://youtu.be/YDfKNsWf0tg

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

six-spindle automatic lathe with 6 main spindles with max. nominal diameter D=51mm
spindle drum with firth coupling,
- CNC cross slide: according to diagram
- Cut-off slide XX VI linear turret
- Gripper for backworking in position 6 with independent, variable speed
- Workpiece conveyor belt
- Additional coolant pump with switchable double filter (18 bar)
- 1x additional variable tool drive
- Loading magazine: Rear bundle loader IEMCA PRA 52/42F with initial and residual piece sorting
- chip conveyor with lateral ejection (chip trolley operation)
- Oil operation
Spare part included in delivery: 1 piece BECKHOFF Industrie PC
Without tooling or optional
Option: scope of tooling is subject to negotiation
The scope of delivery regarding the tooling equipment could be different like pictures.

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

CNC automatic lathe, second-hand
Model: DMG Sprint 42 linear
Year of manufacture: 2007
Control: Fanuc 160i
Main spindle: max. 6500 rpm, C-axis
counter spindle: max. 6500 rpm, C-axis
number of controlled axes: 6
max. bar diameter: 42mm
Number of tool stations: 8
driven stations: 9
automatic loading magazine: IEMCA BOSS 545 -E 32 LL-, year 2006
coolant cooler with pump
The machine could be visited under power.
The scope of delivery regarding the tooling equipment could be different like pictures.
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: CNC swiss type turning machine
Manufacturer: Gildemeister
Type: Sprint 20/8
Yob: 2013
KSS- high pressure unit
2 X-axes / 2 Y-axes / 2 Z-axes / 2 C-axes
Main spindle speed: max. 10,000 rpm
Counter spindle speed: max. 10,000 rpm
Driven tools main spindle: 5 pieces
Driven tools counter spindle: 5 pieces
Bar passage Ø20mm as long lathe / Ø25mm in short lathe mode
Kraft & Bauer fire extinguishing system
Scraper belt chip conveyor
FMB bar feeder
The machine could be visited under power.

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: multi spindle automatic lathe
Manufacturer: Schütte
Type: SF67
Yob: 1981
6 main spindles
max. bar diameter D=67mm

Picture link: https://drive.google.com/drive/folders/1ME7PEicn6HA2wHsc2Cme4m8iwkTs3_DB?usp=sharing

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

6 main spindles with max. 7.000 rpm and max. spindle nominal diameter 32mm
1 counter spindle with max. 10.000 rpm
2 spindles for backworking with max. 10.000 rpm
Control: Siemens Sinumerik 840D PL double PCU
Software: S7-Project version AHSs7_A2
Tool interfaces: HSK
Filter unit: Knoll SF2000/Turbo-3
Water recooling unit: Hydac / type BL 172-19
Axes:
Position I         transverse x/z;          longitudinal z
Position II        transverse x/z;          longitudinal z
Position II        transverse x/z;          longitudinal z
Position iV      transverse x/z/y;       longitudinal x/z(y)
Position V       transverse x/z;          longitudinal x/z
Position VI      transverse x/z;          z (pick-up spindle)
Position VII     longitudinal change heads with chuck clamping
Position VIII    x/z/y
Position VIIII    x/z/y
Tooling: 1 piece polygonal impact device,
2 pieces drilling/milling device axial,
1 tool head transverse with 3 tool places,
2 spare quills lengthwise,
3 pieces drilling/milling device radial,
16 tool holders transverse,
31 tool holders lengthwise,
loading magazine: IEMCA SIR 36P, type 33, year 2010
The machine could be visited under power.
The scope of delivery regarding the tooling equipment could be different like pictures. All information is based on the information provided by the sender and manufacturer, errors excepted.
video link: https://youtu.be/SJslr6yzwCQ
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
subject to sale and mistakes

-sold-

bar feeder, second-hand
manufacturer: IEMCA
model: PRA 40/33/P
year of construction: 1992
rack type loader, newly painted

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: CNC Rotary transfer machine
Manufacturer: Eubama
Type: S6
Yob: 2009
The machine is currently fed with blanks by feeder; the machine can also be operated as a bar automat. An interface for IEMCA PRA [ e.g. PRA52F] is available. A sawing station is available.

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: SF20 DNT
Yob: 1987
six main spindles
for bars up to D=20mm
electronic cam control Balluff
gripper in position 6, sorting chute
Magnetic belt chip conveyor
Tapping couplings
Interface for: Bar loader IEMCA PRA
Bar feeder IEMCA PRA40/33/F
Many accessories
Scope of delivery without the blue chip conveyor

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: Multislide cnc automatic lathe
Manufacturer: DMG Gildemeister
Type: MSL42-7
Yob: 2008
7-axis machine
nominal passage D=42mm
2 tool turrets
oil mist extraction
loading magazine IEMCA BOSS 545 E/32L; rack type loader
chip conveyor
Fanuc CNC control
The scope of delivery of the machine tool may differ from the pictures.

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

six-spindle automatic lathe with 6 main spindles with max. nominal passage D=32mm, 3 counter spindles

control: Siemens SINUMERIK 840SL
main spindles: 6 motor spindles D32 mm, 7.000 rpm, 18,5 Nm to 50 Nm
Counter spindles: 3, one each in position VI, VIII and IX, 10,000 rpm
Cross slide units, transverse: 8 pieces, in position I to V, as well as VIII and IV
Slide units, longitudinal: 5 pieces, in position I to V

Transmit and shell transformation (TRACYL)
Control function: transformation "double eccentric" (2RPT) for Z-slide longitudinal as Y-axis
Cooling lubricant preparation unit
Palletising device
Giovanni Cucchi DBM 632 bar feeder
fire extinguishing system
Tool monitoring: Artis 8 channel, sensorless
Collet system: Hainbuch Spanntop
and much more...

Video link: https://www.youtube.com/watch?v=NntbLFKgSVc

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

pressing force: 160to
yob: 12/1993
stroke rate: 20 - 150 1/min
stroke height: 20 - 120 mm
ram adjustment: 1 - 100 mm
installation height: 550 mm
Table clamping surface approx.: 1,150 x 900 mm
Plunger clamping surface approx.: 1,100 x 700 mm
Drop-through opening in the table: 1000 x 330 mm
Control system: Siemens
Unidor monitoring system
Including roller feed:
Manufacturer: Zehnder & Sommer
Type: EV 420 AG
Year of construction: 2009
Belt width max. / 420 mm
Sold without oiler, without roller block bars,

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: CNC-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: A36PC
Yob: 2013
Eight-spindle automatic lathe with 8 main spindles
max. nominal diameter D=36mm
spur-toothed spindle drum
control: Windows / Beckhoff TWIN-Cat

Extract from order confirmation for first delivery, deviation from current status if necessary:
1x preparation for additional spindle speed
1x IEMCA-PRA 52F/35 rear loader, Yob: 2007
1x rest piece sorting device
1x workpiece collecting device with belt conveyor
1x Knoll coolant HD system SF2000/Turbo-3
1x hinged belt chip conveyor
1x Kraft & Bauer fire extinguishing system
1x pressure relief flaps
1x oil mist extraction system
1x additional tubes for bar guide for bar diameter 10 - 28mm
Position I longitudinal: Drive spindle with HSK with internal coolant supply
Position I transverse: CNC compound slide, transverse
Position II longitudinal: CNC compound slide, for longitudinal slide
Position II transverse: CNC compound slide, transverse
Position III longitudinal: Drive spindle with HSK with internal coolant supply
Position III transverse: Preparation for pneumatic and electric stamping device
Position IV: Additional spindle speed
Position IV longitudinal: Preparation for CNC compound slide, longitudinal, electric and hydraulic
Position IV transverse: Electrical preparation for cross drilling device
Position V: Additional spindle speed
Position V longitudinal: Preparation for CNC compound slide, longitudinal, electric and hydraulic
Position V transverse: CNC compound slide, transverse; electrical preparation for transverse drilling device
Position VI longitudinal: preparation for pneumatic and electric marking device
Position VI transverse: CNC compound slide, transverse
Position VII longitudinal: pick up for rear-side machining, drive for variable speed; electrical preparation for rear-side machining with driven tool
3x variable tool drive [positions A, B, D]
1x length query on cover strip by Detector

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: CNC-controlled multi-spindle automatic lathe
Manufacturer: Tornos
Type: Multiswiss 6x14
Yob: 2015

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: cam-controlled multi-spindle automatic lathe
Manufacturer: Gildemeister
Type: GM26AC
Yob: 1995
six main spindles
for bars up to D=26mm
pick up in position 6
bar loading magazine IEMCA PRA with Pietro Cucchi PB30
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Machine type: CNC controlled multi spindle automatic lathe
Manufacturer: MORI SAY
Type: TMZ 8/67 CNC
Yob: 2018

Double four-spindle machine, eight-spindle machine

with spindles-drum locking by means of 3 HIRTH-type frontal rings and spindles set for HAINBUCH BZI SK80 collets
equipped with twin CNC systems model SINUMERIK SOLUTION LINE 840D SL for the control of:

indexing speed of the spindles drum with bar feed at station 1
speed and orientation of each of 8 main spindles
speed and position of each of 8 frontal slides
speed and position of each of 7 compound slides
speed and position of the cut-off slide at station 8
for a total of 30 CNC-controlled axes, with the possibility of requesting further upgrades from the manufacturer.

Machine equipped with the following optional items:

BAR LOADER
automatic bar feeder model PB 60 by CUCCHI BLT for bars L = 3 m, bundle loader, with rotating centering and fork devices, elastic bushings, 2 proportional valves, double bar feeding

CHIP DISPOSAL SYSTEM
removable coolant tank complete with:  Conveyor for long/short chipping material, self-cleaning sieve, magnetic filter. Additional conveyor for transporting chips in the direction perpendicular to the main conveyor

PARTS REMOVAL SYSTEM
air operated chute complete with: Conveyor belt, external parts collection bin

DEVICES FOR BACKWORKING
Pick-up spindle with external clamping, complete with: Counter spindle drive (axis S08), pneumatic ejector, hydraulic collet cleaning system, internal flushing, counter machining slide with CNC control of radial movement (axis X8).

Additional material stop

FRONT SLIDE EQUIPMENT
Quick-change drill holder with interface VDI 30 for collets type ER,
KOMET compact CNC-drive unit for internal machining and internal thread chasing (drive included), Centred tool holder for KOMET compact CNC drive unit

SPECIAL EQUIPMENT
Direct measurement of spindles, tool monitoring system

CROSS SLIDE AND CUTTING-OFF DEVICE
Cutting blade holder, Static flat form turret tool holder VDI 30, Turret tool holder VDI 30, Drilling tool holder VDI 30, Slide for vertical movement (Y-axis full) of cross slide with receptacles for 3 static tool holders, Flat form tool holder VDI 16 X 16 for slide with vertical movement (Y-axis), CNC-controlled rotating tool holder for thread milling and polygon generation (drive included)

HIGH PRESSURE SYSTEMS

LOSMA F5 high pressure cutting oil filtration system complete with: external tank (1000 litres capacity), high pressure pump (18.5 kW, 70 bar, 100 litres/min), filling pump, self-cleaning filter (25 micron), control panel for the high pressure system,

AEROSOLS ABATING and FIRE PREVENTION SYSTEMS

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: CNC-controlled multi-spindle automatic lathe
Manufacturer: Schütte
Type: S51 PC
Yob: 2008
Six-spindle automatic lathe with 6 main spindles
max. nominal diameter D=51mm
hirth-coupled spindle drum,
Control: Software SICS 2000 / Windows 2000 / Beckhoff Twincat

Position I: cross slide X-I; longitudinal slide Z-I
Position II: compound slide cross XZ-II; longitudinal slide Z-II
Position III: compound slide cross XZ-III; longitudinal slide Z-III
Position IV: compound slide cross XZ-IV; compound slide longitudinal ZX-IV
Position V: cross slide X-V; compound slide longitudinal ZX-V
Position VI: cross slide X-VI; pick up for rear machining; second cross slide XX-VI

Coolant tank with hinged belt chip conveyor;
Coolant pump with two pressure connections: q= 180 l/min, p1 bar; q=70 l/min, p=7 bar;
Workpiece collecting device with belt conveyor (low-damage workpiece removal);
Sorting device for initial and offcuts;
IEMCA back loader PRA52F/42 (Profibus);
Preparation: Teleservice; oil mist filter; second variable speed

The scope of delivery regarding the tooling equipment could be different like pictures.

Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

-sold-

Article: Dryer for plastic granulate
Manufacturer: Koch Technik
Type: CKT110
Control system: SIEMENS S7
Year of construction: 2014
possible dry air volume: 110 m³/h
The machine has only run twice
Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
